Name: Stranding High Speed Double Twist Tying Machine
Brand: Stranding High Speed Double Twist Tying Machine
SKU: HT-800P
Rating: 4.6 (187 reviews)

traits Galerie Description de produit Demandez une citation

traits

Caractéristiques

Model Number: HT-800P

Usage: Stranding

Informations de base

Model Number: HT-800P

Conditions de paiement et expédition

Packaging Details: wooden by container.

Supply Ability: 20 Set/Sets per Quarter

Description de produit

Product Description

Features:

Ø Magnetic powder clutch tension auto control can ensure constant tension from
empty bobbin to full bobbin;
Ø Synchronous belt drive; mechanical pitch change; stable pitch;
Ø Bobbin loading and unloading is controlled by hydraulic with motor; it’s easy to
oprtate.

Technical Specification:

Machine model	HT-500P	HT-630P	HT-800P	HT-1000P	HT-1250P
Sectional area twisted(mm2)	0.50-2.50	0.75-6.00	2.50-16.0	6.0-25.0	10.0-50.0
Inlet wire dia.	0.08-0.45	0.25-1.00	0.30-1.60	0.40-1.80	0.60-2.50
Twisting pitch	4.22-39.64mm	11.15-100mm	17-200mm	35-200mm	35-300mm
Main motor power	AC7.5KW	AC11KW	AC18.5KW	AC22KW	AC37KW
Max. rotating speed	2200RPM	1800RPM	1200RPM	1000RPM	800RPM
Tension control	Magnetic powder clutch automatic adjustment
Traverse type	Polished rod traverse, wire lay is adjustable
Wire break sensor	Digital display, machine auto-stop if wire break
Rotating direction	S.Z Direction
Spooling bobbin	500mm	630mm	800mm	1000mm	1250mm

------------------------------------------

Finished Products

HT-630P Bunching machine:


Multi wire drawing machine with annealer(4/8/10/16/24wires)	8mm Rod breakdown wire drawing machine with annealer(1/2wires)	9.5mm Aluminum Rod breakdown wire drawing machine with online annealer	Electrolytic Tin-plating Machine(3000Sn/6000Sn/10000Sn)


Multi wire draiwng machine with annealer(4/8/10/16/24)	All kind of double twisting buching machine	Extrusion machine	Stell bobbin
